30×120 Cleanroom Dimmable Integrated IP65 LED Panel Lights 40W

The IP65 integrated LED panel light is designed for applications in dusty or wet / damp environments where before this was just not possible with normal LED panels. This Panel Series is also designed to the good energy saving panel with 50,000 hours long life, and 90% uniformity across the emitting surface.

It enables customers to recover initial investment quickly and greatly reduce the maintenance cost.

Item: 30x120 IP65 Integrated LED Panel Light

Power: 36W /40W /48W /54W /60W /72W /80W

Input Voltage: AC220-240V/ AC85~265V

Color Temperature: Warm White, Natural White, Cool White

Lifespan: ≥50000 Hours

Send email to us Download as PDF

Products categories

Product Detail

Installation Guide

Project Case

Product Video

1. Product Features of 30x120 IP65 Integrated Waterproof LED Panel Light.
•Using aluminum alloy shell, with PS diffuser, Have good heat dissipation ability and optical effects.
•Over 90% light transmission makes the light softly and brightly, no flickering.
•Product quality: all products before they leave the factory after several strict examination, and has a number of safety certification.
•Emit NO UV or IR radiation, environmentally friendly.
•Stable durable: 3 years, from radio interference, not pollute the environment.
•Distribute light evenly, absolutely NO bright spot or dark spot on panel.
•Prevent lampblack, dustproof, anti-mosquito.

2. Product Specification:

Model No	PL-30120-36W	PL-30120-40W	PL-30120-48W	PL-30120-54W
Power Consumption	36 W	40 W	48 W	54 W
Luminous Flux (Lm)	2880～3240lm	3200～3600lm	3840～4320lm	4320～4860lm
LED Qty(pcs)	192 pcs	204 pcs	252 pcs	300 pcs
LED Type	SMD 2835
Color Temperature (K)	2800 - 6500K
Color	Warm/Natural/Cool White
Light Efficiency (lm/w)	>80lm/w
Dimension	298119812mm
Beam Angle (degree)	>120°
CRI	>80
Power Factor	>0.95
Input Voltage	AC85V - 265V
Frequency Range (Hz)	50 - 60Hz
Working Environment	Indoor
Material of Body	Aluminum alloy frame and PS Diffuser
Frame Color RAL	Pure white/RAL9016; Silver
IP Rating	IP65
IK Grade	IK06
Operating Temperature	-20°~65°
Dimmable Solution	Dali/0~10V/PWM/Triac Optional
Life span	50,000hours
Warranty	3 Years
